PEEK insulators deliver unmatched reliability in extreme voltage environments, combining dielectric strength exceeding 17 kV/mm with continuous thermal stability up to 260°C. At Dongguan PRES Group Co., Ltd., we manufacture premium PEEK products—including granules, sheets, rods, tubes, powders, and high-performance 3D printing filaments—specifically engineered for OEM partners serving aerospace, energy, automotive, and industrial sectors worldwide.
When voltage levels push beyond conventional limits, material selection becomes critical. PEEK (polyether ether ketone) has emerged as the insulation material of choice for extreme environments where failure is not an option.
PEEK's electrical insulation capabilities are industry-leading:
- Dielectric strength: 17–25 kV/mm, significantly outperforming polyethylene, PVC, and many fluoropolymers
- Volume resistivity: Approximately 10⊃1;⁴ to 10⊃1;⁶ Ω·m (or 10⊃1;⁶ Ω·cm), ensuring minimal leakage current even under high-voltage stress
- Dielectric constant: Stable at 3.2–3.5 across wide frequency ranges, critical for high-frequency applications
- Dissipation factor: As low as 0.0015, minimizing energy loss and heat generation
At PRES Group, our PEEK granules and semi-finished products maintain these specifications consistently, batch after batch, thanks to our stringent quality control and ISO-certified manufacturing processes.
One of PEEK's defining advantages is its ability to maintain insulation performance at elevated temperatures:
- Continuous service temperature: 250–260°C (482–500°F)
- Short-term exposure tolerance: Up to 300°C (572°F)
- Glass transition temperature (Tg): 143°C; melting point: 343°C
This thermal resilience is crucial in high-voltage environments where electrical losses generate heat. Unlike XLPE (limited to 90°C) or polysulfone (softening at 168°C), PEEK-insulated components continue operating safely well beyond these thresholds.
Industry insight: In 800V electric vehicle powertrains, PEEK magnet wire achieves breakdown voltages (BDV) exceeding 10 kV—compared to 6 kV for traditional enamel wires—and demonstrates superior partial discharge inception voltage (PDIV) retention throughout its service life.victrex+1
In aircraft electrical systems operating at 270V DC and higher, PEEK insulators withstand:
- Voltage spikes from lightning strikes and switching transients
- Wide temperature cycling from -55°C to +200°C
- Exposure to aviation fuels, hydraulic fluids, and de-icing agents
PRES Group supplies PEEK rods and machined components to Tier-1 aerospace suppliers who demand zero-defect performance. Our materials meet stringent flame-smoke-toxicity (FST) requirements while maintaining dielectric integrity. [
High-voltage connectors, bushings, and insulating spacers in substations and renewable energy systems benefit from PEEK's:
- Arc resistance: Approximately 190 seconds, preventing catastrophic tracking failures
- Partial discharge resistance: PEEK insulation maintains higher PDIV throughout aging, unlike enamel coatings that degrade
- Moisture resistance: Low water absorption (<0.5%) ensures stable performance in humid or submerged conditions
The shift to 800V BEV architectures has accelerated PEEK adoption:
| Application | PEEK Advantage |
|---|---|
| Hairpin motor windings | Uniform insulation thickness (60–300 microns) with eccentricity <5% |
| Battery pack insulators | Thermal stability improves safety; lightweight design extends range |
| High-voltage connectors | Dimensional stability during high-temperature soldering; high dielectric strength |
| Charging infrastructure | Durability in high-frequency charging cycles; chemical resistance to coolants |
Customer testimonial (anonymized for ): *"PRES Group's PEEK sheets allowed us to machine custom insulators for our 1000V DC charging station prototypes. The material's consistency and machinability reduced our development time by 40%."* — Senior Engineer, European EV Infrastructure Manufacturer
As a China-based manufacturer serving global OEMs, wholesalers, and producers, Dongguan PRES Group Co., Ltd. differentiates itself through:
From raw PEEK polymer compounding to final semi-finished products (granules, sheets, rods, tubes, powders, 3D filaments), we control every step. This ensures:
- Material purity: Minimal contaminants that could create electrical weak points
- Consistent crystallinity: Optimized for maximum dielectric strength and thermal stability
- Traceability: Full batch documentation for aerospace and medical certifications
Every production lot undergoes:
- Dielectric strength testing (ASTM D149) to verify ≥17 kV/mm performance
- Volume resistivity measurement to confirm >10⊃1;⁴ Ω·m insulation capability
- Thermal analysis (DSC, TGA) to validate continuous service temperature ratings
- Dimensional precision checks for sheets, rods, and tubes to ensure tight tolerances in machined parts
We don't just sell stock PEEK—we engineer solutions:
- Glass-filled or carbon-filled PEEK for enhanced mechanical strength in structural insulators
- ESD-grade PEEK for semiconductor handling applications where controlled dissipation is required
- Custom extrusion profiles for specialized tubing and wire insulation geometries
- 3D printing filaments optimized for FDM/FFF processes, enabling rapid prototyping of complex insulator designs
Choosing the right insulator requires understanding trade-offs. Here's how PEEK stacks up:
| Property | PEEK | PTFE | Ultem (PEI) | XLPE |
|---|---|---|---|---|
| Dielectric Strength (kV/mm) | 17–25 | 50–100 | ~20–25 | 15–20 |
| Continuous Temperature (°C) | 250–260 | 260 | 170 | 90 |
| Tensile Strength (MPa) | 90–100 | 25–35 | 105 | 20–30 |
| Flexural Modulus (MPa) | ~3,900 | ~495 | ~3,300 | ~800 |
| Chemical Resistance | Excellent (acids, bases, solvents) | Outstanding | Good | Limited |
| Creep Resistance | Excellent | Poor | Good | Moderate |
| Cost | High | Moderate-High | Moderate | Low |
Key takeaway: While PTFE offers superior dielectric strength, PEEK provides far better mechanical properties, dimensional stability, and creep resistance—making it the preferred choice for structural insulating components under mechanical load in extreme environments. [gtweed]
- Maximum operating voltage (AC/DC, RMS/peak)
- Required dielectric strength (kV/mm) with safety factor (typically 2–3×)
- Frequency range (affects dielectric constant and loss)
- Temperature range (continuous and peak)
- Chemical exposure (fuels, solvents, acids, bases)
- Mechanical loads (compression, tension, vibration)
- Humidity or immersion conditions
- Unfilled PEEK: Maximum dielectric strength and chemical resistance
- 30% Glass-Filled PEEK: Enhanced stiffness and creep resistance for structural parts
- ESD PEEK: Controlled surface resistivity (10⁵–10⁹ Ω) for static-dissipative applications
- Granules: For injection molding or extrusion of custom parts
- Sheets: For CNC machining of flat insulators, spacers, and plates
- Rods: For bushings, sleeves, and cylindrical insulators
- Tubes: For wire insulation, sleeves, and hollow components
- Powders: For coating applications or specialized compounding
- 3D Printing Filaments: For rapid prototyping and low-volume production
Request samples from PRES Group for:
- In-house dielectric testing per your standards
- Thermal aging studies to project service life
- Prototype machining to verify manufacturability
Recent research demonstrates that PEEK nanocomposites incorporating nano-silica or hyperbranched polyester can achieve:
- Breakdown voltages exceeding 13 kV in composite wire insulation
- DC insulation resistance reaching 2×10⊃1;⁶ Ω, an order of magnitude improvement over standard PEEK
- Enhanced thermal conductivity for better heat dissipation in high-power applications
PRES Group is actively developing nanocomposite PEEK formulations in partnership with research institutions, with commercial availability expected within 18–24 months. Our OEM partners will gain first access to these next-generation materials.
With over a decade of specialization in high-performance polymers, Dongguan PRES Group Co., Ltd. has become the preferred OEM manufacturing partner for:
- European automotive Tier-1 suppliers requiring IATF 16949-certified PEEK components for EV powertrains
- North American aerospace primes demanding AS9100-compliant materials for flight-critical insulators
- Asian energy equipment manufacturers seeking cost-effective, high-quality PEEK sheets and rods for high-voltage switchgear
What sets us apart:
- English-speaking technical support for seamless communication
- Flexible MOQs accommodating both prototyping and mass production
- Fast lead times: 7–10 days for stock items; 15–20 days for custom extrusions
- Competitive pricing: Direct factory pricing without trading company markups
- Full documentation: Material certificates, test reports, and RoHS/REACH compliance
Don't compromise on insulation performance in extreme voltage environments. Whether you're designing 800V EV components, aerospace electrical systems, or renewable energy infrastructure, PEEK from PRES Group delivers the reliability your application demands.
1. Request a free sample kit of PEEK granules, sheets, or rods for evaluation
2. Schedule a technical consultation with our engineering team to discuss your specific requirements
3. Obtain a custom quote for OEM production volumes with lead time guarantees
Contact PRES Group today: Visit our website or email our international sales team to start your project. With PRES Group as your PEEK manufacturing partner, you gain more than a supplier—you gain a strategic ally committed to your product's success in the most demanding voltage environments on Earth.
1. Issuewire. "Technological Innovation for the Electric Vehicle Industry with PEEK High Voltage Insulated Wire." June 16, 2024. [https://www.issuewire.com/technological-innovation-for-the-electric-vehicle-industry-with-peek-high-voltage-insulated-wire-1801993278667239]
2. MarketsandMarkets. "North America PEEK Market." 2026. [https://www.marketsandmarkets.com/Market-Reports/north-america-peek-market-9084049.html]
3. Plastics Today. "Evonik Opens PEEK Magnet Wire Lab to Advance NEV Innovation." [https://www.plasticstoday.com/automotive-mobility/evonik-opens-peek-magnet-wire-lab-to-advance-nev-innovation]
4. Plastics News. "800V BEV powertrain: advanced materials driving efficiency, range, and sustainability." [https://www.plasticsnews.com/sponsored-content/800v-bev-powertrain-advanced-materials-driving-efficiency-range-and/]
5. IEEE Xplore. "Advanced PEEK Nanocomposite Insulation for E-Mobility." [https://ieeexplore.ieee.org/abstract/document/11642514/]
6. Victrex. "Benefits of PEEK Insulation in High-Voltage Electric Machines." Whitepaper, September 2024. [https://www.victrex.com/-/media/downloads/whitepapers/ahv-victrex-whitepaper_benefits-peek-insulation-in-high-voltage-electrical-machines-en-09-2024.pdf]
7. Victrex. "Benefits Of PEEK Insulation in High-Voltage Electrical Machines." [https://www.victrex.com/en/xpi-whitepaper]
8. Eureka (PatSnap). "PEEK Electrical Insulation: Advanced Material Properties." April 13, 2026. [https://eureka.patsnap.com/materials/peek-electrical-insulation]
9. Eureka (PatSnap). "PEEK Dielectric Material: Comprehensive Analysis Of." April 13, 2026. [https://eureka.patsnap.com/materials/peek-dielectric-material]
10. Eureka (PatSnap). "How PEEK Polymer Enhances Electrical Insulation in Electronics." [https://eureka.patsnap.com/report-how-peek-polymer-enhances-electrical-insulation-in-electronics]
11. Weerg. "ULTEM (PEI) vs PEEK: Differences, Advantages and." May 15, 2025. [https://www.weerg.com/guides/ultem-vs-peek]
12. Garlock (GT Weed). "PEEK vs PEK vs PTFE Materials." January 16, 2023. [https://www.gtweed.com/materials/peek-vs-pek-vs-ptfe/]
13. DX Seals. "Exploring the Use of PEEK in Electrical Insulation Systems." February 8, 2025. [https://www.dxtseals.com/articles/exploring-the-use-of-peek-in-electrical-insulation-systems]
14. HRDJM. "Why Choose PEEK for High-Performance Insulating Components." July 17, 2025. [https://www.hrdjm.com/knowledge-base/peek-for-high-performance-insulating-components-benefits.html]
15. PEEKCHINA. "Why PEEK is Ideal for Electrical Insulation?" [https://www.peekchina.com/blog/peek-electrical-properties.html]
16. ReadyPlastics. "PEEK Properties and Datasheet." May 8, 2026. [https://www.readyplastics.com/resources/materials/peek/properties]
17. Fluorocarbon Group. "PTFE vs PEEK - What are the differences?" November 6, 2020. [https://fluorocarbon.co.uk/resources/blog/ptfe-vs-peek/]
18. Plastic Machining Inc. "The Ultimate Guide to PEEK Polymer Properties." October 10, 2024. [https://www.plasticmachininginc.com/the-ultimate-guide-to-peek-polymer-properties/]
Q1: What is the maximum voltage PEEK insulators can handle?
A: PEEK's dielectric strength of 17–25 kV/mm means a 1mm-thick PEEK insulator can theoretically withstand 17,000–25,000 volts before breakdown. In practice, engineers apply safety factors (2–3×), so 1mm PEEK is commonly rated for 6–10 kV applications. Actual performance depends on geometry, frequency, and environmental conditions. [eureka.patsnap]
Q2: Can PEEK be used in 800V electric vehicle systems?
A: Yes. PEEK is increasingly specified for 800V BEV powertrains, particularly in hairpin motor windings, battery pack insulators, and high-voltage connectors. PEEK magnet wire achieves BDV >10 kV and maintains PDIV throughout thermal aging, outperforming traditional enamel insulation. [issuewire]
Q3: How does PEEK compare to PTFE for electrical insulation?
A: PTFE has higher dielectric strength (50–100 kV/mm vs. 17–25 kV/mm for PEEK), but PEEK offers far superior mechanical strength (90–100 MPa vs. 25–35 MPa), creep resistance, and dimensional stability. PEEK is preferred for structural insulating components; PTFE excels in pure insulation applications without mechanical load. [gtweed]
Q4: Does PEEK maintain insulation properties at high temperatures?
A: Yes. PEEK maintains stable dielectric properties up to 250–260°C continuously and 300°C short-term. Volume resistivity remains >10⊃1;⁴ Ω·m even at elevated temperatures, unlike XLPE or polysulfone which degrade significantly above 90–168°C. [eureka.patsnap]
Q5: What PEEK product forms does PRES Group supply for insulator manufacturing?
A: PRES Group offers PEEK granules (for molding/extrusion), sheets (for CNC machining), rods, tubes, powders, and high-performance 3D printing filaments. All products are manufactured in our Dongguan facility with full traceability and certifications for aerospace, automotive, and industrial applications.
