PEI 9085 3D Printing Filaments

Name: PEI 9085 3D Printing Filaments
Brand: PRES
SKU: 576845907
Rating: 5.0 (66 reviews)

(Boron Nitride NanobBarb, abbreviated as BNNB) This material is hexagonal boron nitride crystals nucleated on the outer surface of boron nitride nanotubes. Irregular hexagonal boron nitride crystals enhance the cross-linking between nanotubes and PEI.

Material:	Boron nitride nanotubes resinforced PEI
diameter:	1.75mm
weight:	1 kg/roll
length:	335m
Availability:

Quantity:



Inquire Add to Basket

Model:
PEI 9085
Brand:
PRES

Product Description

PEI 9085 3D Printing Filaments Product Description

		High-temperature resistant
	1.Glass transition temperature: 215-217 °C 2.Heat distortion temperature: 220°C 3.Long-term using temperature: 170°C 4.Short-term using temperature: 200°C
		High printing precision
	9085 is an amorphous material with a relatively high glass transition temperature and softening temperature, offering better printing accuracy than PEEK material
		Easy printing
	Boron nitride nanotubes can withstand high temperatures up to 900°C, while the nozzle temperature for printing PEI9085 is only 350-380°C. Therefore, they are less likely to clog the nozzle and are easier to print.
		Flame retardant UL-94V0

|PEI 9085 Advantages

BNNB reinforced PEI 9085 3D printing filament has the following advantages:

●Increase the tensile strength of PEI9085 by 30% to 50%

●The tensile strength can be comparable to or even higher than that of PEEK material

● Increase impact strength by 20-25%

● Increase the heat distortion temperature of the material

● Enhance high-temperature stability and durability

●It has a higher printing success rate than PEEK

●The printing success rate is as high as 95%

●It is widely applicable to FDM/FFF printing models

|PEI 9085 DATA SHEET

Item	Unit	Value
Tensile strength	MPa	115
Elongation at break	%	5.8
density	g/cm³	1.3
Bending modulus	GPa	2.8
Glass transition temperature	℃	215
Heat distortion temperature (℃)	℃	220

Shipping & Payment

We can accept US dollars, rubles, and Chinese yuan

We can ship by sea,by air and express.

UPS

DHL

FEDEX

PEI 9085 Data Sheet

Physical Properties	Units	Test	value
Density	g/cm³	D792	1.28
Water Absorption, 24 hrs.	%	D570	0.25
Water Absorption, Saturation	%	D570	1.25
Mechanical Properties
Tensile Strength	MPa	ISO527	110
Tensile Modules	MPa	ISO527	3200
Flexural Strength	MPa	ISO178	160
Flexural Modulus	GPa	ISO178	3.3
Hardness Rockwell M	-	ASTM D785	109
Coefficient of Linear Thermal Expansion	cm/cm/°C	D696	5.6*10^-5
Glass Transition Temperature	ºC	D3418	210
Thermal Conductivity	W/m-°C	ISO 8302	0.22
Flame retardant	-	UL94	V-0
Electrical Properties
Volume Resistivity	Ω.cm	IEC 60093	1.E+15
Dielectric Constant	@1.1 GHz		3.01
Dissipation Factor	@ 5 GHz		3.02
Surface Resistivity	Ω	IEC 60093	1.E+15
