Anti-static PEI Granules for Injection

Product: Injection Grade Antistatic PEI Pellets
Core Advantages:
ESD Safety: Permanent control (10⁸–10¹⁰ Ω/sq), no carbon black migration.
Cleanroom Ready: Ultra-low particle generation for ISO Class 5/Class 100 environments.
Thermal Stability: 170°C continuous use, HDT 200°C, UL94 V-0.
Process Efficiency: High melt flow rate, excellent release, sterilizable.
Applications: IC trays, surgical instruments, aircraft interiors, EV charging parts.

Material:	Anti static PEI
Electrostatic protection value:	ESD E4-E9 ESD E5-E8 ESD E6-E9 E9-E11
MOQ:	5kg
Packing:	25kg/bag in box
Availability:

Quantity:



Inquire Add to Basket

Model:
PEI-ESD100
Brand:
PRES

Product Description

| Injection Grade Antistatic PEI Pellets | ESD-Safe & High Performance

Injection Grade Antistatic PEI (Polyetherimide), often branded as Ultem, is an amorphous, high-performance thermoplastic offering an outstanding combination of inherent flame retardancy, high rigidity, and long-term dimensional stability. Engineered with permanent ESD protection (10⁸–10⊃1;⁰ Ω/sq), these pellets provide a cost-effective alternative to PEEK for precision molded components requiring electrostatic safety and continuous service up to 170°C.

⚡ Permanent ESD Control

Stable surface resistivity without carbon black blooming, protecting sensitive electronics during automated handling.

Inherent Flame Retardancy

UL94 V-0 rated without additives. Low smoke generation and oxygen index >47%, ideal for aircraft interiors.

️ Chemical & Hydrolysis Resistance

Resists automotive fluids, hot water, and steam. Excellent for under-hood components and sterilization.

⚙️ High Flow & Precision

Exceptional melt flow characteristics allow complex, thin-wall molding with tight tolerances.

✔️ Metal Replacement: High strength-to-weight ratio reduces system costs.
✔️ Food & Medical Grade: Compliant with FDA and USP Class VI standards.
✔️ Colorable: Natural amber tone can be pigmented to custom colors.

| Antistatic PEI Pellets Applications & Use Cases

Ideal for high-volume injection molding where ESD safety, stiffness, and thermal resistance are required at a competitive price point.

Aerospace & Aircraft Interiors

ESD-Safe Interior Panels: Lightweight and compliant with FAR 25.853.
Seat Components: High rigidity and aesthetic finish.
Cable Connectors: Flame retardant and chemical resistant.

Automotive Electronics

Connectors & Sensors: High-temperature reflow capable.
Under-Hood Modules: Resists engine oils and glycols.
EV Charging Components: ESD-safe and flame retardant.

Medical & Labware

Surgical Trays: Autoclavable and dimensionally stable.
Lab Instrument Covers: Chemical resistance to solvents.
ESD-Safe Drug Delivery: Protects sensitive drug formulations.

Industrial & Consumer

Food Processing Parts: FDA compliant and steam sterilizable.
Printer Components: Heat resistance and ESD control.
Microwave Cookware: High heat tolerance and food safe.

| Injection Grade Antistatic PEI Data Sheet

Technical Specifications (Antistatic PEI Pellets)
Property	Units	Test Method	Typical Value
Electrical
Surface Resistivity	Ω/sq	ASTM D257	10⁸ – 10⊃1;⁰
Volume Resistivity	Ω·cm	ASTM D257	>10⁹
Thermal
Glass Transition Temp (Tg)	°C	D3418	~217
Heat Deflection Temp (1.8MPa)	°C	ASTM D648	~200
Continuous Use Temp	°C	-	170
Mechanical
Tensile Strength	MPa	ISO 527	105 – 115
Flexural Modulus	GPa	ISO 178	3.3 – 3.5
Flammability
Flame Rating	-	UL94	V-0 (0.41mm)
Processing
Melt Temperature	°C	-	340 – 425
Mold Temperature	°C	-	65 – 175

| FAQs – Injection Grade Antistatic PEI Pellets

Q1: How does Antistatic PEI compare to PEEK in terms of cost?

Antistatic PEI offers significant cost savings compared to PEEK while maintaining high heat resistance (up to 170°C) and inherent flame retardancy. It is the preferred choice for applications where extreme chemical resistance of PEEK is not required but ESD safety and structural rigidity are essential.

Q2: Can PEI be sterilized for medical applications?

Yes. PEI is highly resistant to hydrolysis and can withstand repeated sterilization cycles, including autoclaving (steam), gamma radiation, and EtO (ethylene oxide) gas, making it ideal for reusable medical devices.

Q3: Is PEI naturally flame retardant?

Absolutely. Unlike many plastics, PEI possesses inherent flame retardancy due to its chemical structure. It achieves a UL94 V-0 rating without the need for halogenated additives, resulting in low smoke generation and toxicity.
