Artificial intelligence is accelerating data center expansion and increasing rack power density. As a result, cooling systems must deliver stable temperature control, high uptime, and reliable coolant circulation. Liquid cooling is becoming increasingly important for direct-to-chip, immersion, and hybrid cooling architectures. [racksolutions] [businesswire]
In these systems, solenoid valves and electromagnetic coils control the movement of refrigerants, water-glycol mixtures, dielectric fluids, and other cooling media. A failed coil or valve can interrupt coolant delivery, reduce thermal efficiency, trigger alarms, or contribute to costly downtime.
From my perspective as an engineering materials specialist, the key lesson is straightforward: a solenoid coil is not only an electrical component. Its reliability depends on the interaction between:
- Electrical design
- Coil encapsulation
- Bobbin and housing materials
- Coolant compatibility
- Thermal cycling
- Dimensional stability
- Manufacturing quality
PRES supports this demanding application with high-performance engineering plastics, including PEEK, PPS, PPSU, PSU, and PEI, supplied as pellets, sheets, rods, and tubes. Through CNC machining, injection molding, and custom processing, PRES can provide both raw materials and finished precision plastic components.
Traditional air cooling remains practical for many conventional server loads. However, AI training and high-performance computing can create substantially higher and more continuous thermal loads. Industry reporting indicates that many data center operators consider existing cooling capacity insufficient, while liquid-cooling adoption and prefabricated cooling modules continue to grow. [airsysnorthamerica]
The main cooling architectures include:
| Cooling architecture | Typical function | Material challenge |
|---|---|---|
| Chillers | Remove heat from a facility cooling loop | Temperature cycling, pressure, refrigerant exposure |
| Refrigerant circuits | Transfer heat through vapor-compression systems | Chemical compatibility and sealing reliability |
| Direct-to-chip cooling | Circulate coolant through cold plates mounted on processors | Continuous flow, cleanliness, dimensional control |
| Heat exchangers | Transfer heat between separate circuits | Thermal cycling and fluid resistance |
| Immersion cooling | Submerge electronics in dielectric fluid | Long-term fluid compatibility |
| Cooling distribution units | Isolate and regulate facility and technology loops | Valve reliability, monitoring, serviceability |
| Cooling towers | Reject heat to the atmosphere | Humidity, corrosion, and outdoor exposure |
Liquid-cooling components therefore operate in systems where flow interruption is not a minor inconvenience. It can affect server performance, equipment protection, maintenance schedules, and service-level commitments.
A solenoid valve converts electrical energy into mechanical movement. When energized, the coil generates a magnetic field that moves a plunger or armature, opening or closing the valve. In a cooling system, this action may regulate:
- Coolant inlet and outlet flow
- Bypass circuits
- Pressure relief paths
- Refrigerant supply
- Drain and purge functions
- Redundant cooling branches
- Isolation during maintenance
The coil assembly commonly includes a winding, insulation system, bobbin, encapsulant, terminals, and protective housing. Each part must remain functional despite:
- Repeated heating and cooling
- High electrical duty cycles
- Humidity and condensation
- Vibration from pumps and fans
- Chemical contact
- Pressure and flow fluctuations
- Long periods of continuous operation
A material that performs well in a dry laboratory environment may not perform equally well after years of exposure to coolant, vibration, and temperature changes.
Cooling equipment may experience frequent start-stop cycles, changing coolant temperatures, and localized heat from energized coils. Engineering plastics used in coil bobbins, valve guides, insulators, and housings must retain their shape and mechanical properties across the operating temperature range.
Dimensional stability is especially important where components control magnetic air gaps, guide moving parts, or maintain sealing pressure. Excessive expansion, shrinkage, or creep can affect valve response and leakage performance.
Modern cooling systems may use water-glycol mixtures, refrigerants, dielectric fluids, cleaning agents, corrosion inhibitors, and other formulated media. Chemical compatibility should never be assumed from a polymer's general reputation.
The correct evaluation should consider:
1. Fluid composition
2. Concentration
3. Operating temperature
4. Exposure duration
5. Mechanical stress
6. Pressure and flow conditions
7. Presence of additives
Testing the actual material against the actual coolant is more reliable than selecting a polymer based only on a generic chemical-resistance chart.
Solenoid coil bobbins and insulating components must provide stable electrical isolation over the service life of the equipment. Moisture absorption, surface contamination, and thermal aging can reduce insulation performance.
For this reason, designers should evaluate:
- Dielectric strength
- Insulation resistance
- Comparative tracking behavior
- Moisture absorption
- Thermal aging
- Flammability requirements
The final specification should be aligned with the applicable component, equipment, and end-market standards.
Humidity and condensation can create electrical and dimensional problems. A plastic with low moisture absorption is often advantageous for precision coil components because it can help maintain:
- Stable dimensions
- Consistent dielectric behavior
- Reliable electrical clearance
- Predictable assembly tolerances
This is particularly relevant in facilities where cooling equipment operates near chilled surfaces, outdoor heat-rejection equipment, or humid service environments.
Valve components may remain under compression or mechanical load for thousands of hours. Materials with strong creep resistance can help preserve dimensional accuracy and sealing performance.
PEEK and PPS are often considered for demanding precision components because they combine high-temperature capability with chemical and mechanical performance. The best choice still depends on the specific design, grade, reinforcement, and operating conditions.
The following comparison provides a practical starting point. Final selection should be confirmed using the manufacturer's technical data and application-specific testing.
| Material | Key strengths | Potential applications |
|---|---|---|
| PEEK | Excellent chemical resistance, high temperature capability, wear resistance, strong mechanical performance | Valve seats, guides, insulators, precision coil components |
| PPS | Very low moisture absorption, strong chemical resistance, dimensional stability, good electrical properties | Valve bodies, bobbins, electrical insulation, pump components |
| PPSU | High impact strength, hydrolytic resistance, good toughness at elevated temperature | Durable housings, connectors, fluid-handling components |
| PSU | Good thermal performance, dimensional stability, and resistance to hydrolysis | Structural supports, housings, manifolds, insulating parts |
| PEI | High strength-to-weight ratio, electrical insulation, flame resistance, dimensional stability | Coil bobbins, connectors, sensor mounts, electrical housings |
PEEK may be appropriate when the component requires exceptional chemical resistance, wear resistance, or mechanical performance under demanding conditions.
PPS can be attractive when the design prioritizes low moisture uptake, dimensional stability, electrical insulation, and cost efficiency at high production volumes.
PPSU is useful where toughness and hydrolytic resistance are important. PSU can provide a balanced option for thermal and structural applications. PEI is often considered for electrical components requiring strength, flame resistance, and stable geometry.
These materials are not interchangeable by default. A change in polymer can alter molding shrinkage, machining behavior, dielectric properties, surface finish, and long-term performance.
One common design mistake is evaluating coolant compatibility as a simple "yes or no" question. In practice, polymer performance depends on the interaction of fluid, temperature, time, and stress.
A more useful qualification method is a fluid–temperature–stress matrix:
| Test condition | What it reveals |
|---|---|
| Coolant exposure at room temperature | Baseline chemical compatibility |
| Coolant exposure at maximum operating temperature | Accelerated softening, swelling, or degradation |
| Thermal cycling with coolant present | Dimensional change and fatigue behavior |
| Electrical aging under humidity | Insulation stability |
| Compression or load after immersion | Creep and stress cracking |
| Flow or vibration testing | Wear, erosion, and mechanical durability |
This approach can identify failure modes that a short-term immersion test may miss. It also creates stronger technical evidence for customers, auditors, and design-review teams.
PRES is positioned not only as an engineering plastic supplier but also as an integrated manufacturing partner. This is valuable when customers need to move efficiently from material selection to production.
PRES supplies high-performance polymers in multiple forms:
- Pellets for injection molding and high-volume production
- Sheets for plates, covers, insulation, and fabricated parts
- Rods for turned and machined components
- Tubes for sleeves, guides, spacers, and fluid-handling applications
CNC machining is suitable for:
- Prototype development
- Low- and medium-volume production
- Complex geometries
- Tight-tolerance components
- Design verification before tooling investment
Machined PEEK, PPS, PEI, PSU, and PPSU parts can help engineers validate fit, flow paths, sealing interfaces, and assembly performance before committing to injection molds.
Injection molding becomes attractive when demand increases and repeatability, cycle time, and unit cost become more important. It is commonly used for:
- Coil bobbins
- Valve housings
- Electrical connectors
- Insulating covers
- Manifolds
- Sensor and actuator components
For molded parts, designers must consider gate location, weld lines, shrinkage, fiber orientation, draft angles, and post-molding tolerances.
Some applications require more than standard machining or molding. Custom processing may include:
- Material and grade selection
- Drawing review
- Tolerance analysis
- Prototype iteration
- Machining optimization
- Production scaling
- Inspection and documentation
Working with one partner for both material and component manufacturing can reduce communication gaps and improve traceability.
Before finalizing a plastic component for a cooling system, engineers should document:
1. Operating temperature range
2. Coolant or refrigerant composition
3. Maximum pressure and flow rate
4. Expected electrical duty cycle
5. Humidity and condensation exposure
6. Required dielectric performance
7. Dimensional tolerances
8. Mechanical loads and vibration
9. Fire and regulatory requirements
10. Expected service life
11. Cleaning and maintenance chemicals
12. Production volume and manufacturing method
The supplier should also receive the relevant drawings, 3D models, fluid specifications, and test requirements. This allows the material recommendation to be based on the application rather than on a generic material label.
A robust qualification program should combine material data, engineering analysis, and physical testing.
- Define the failure consequences: Identify whether failure could cause a leak, loss of flow, electrical short, thermal event, or unplanned shutdown.
- Screen candidate polymers: Compare thermal, chemical, electrical, and mechanical requirements.
- Review the manufacturing process: Confirm whether CNC machining, injection molding, or another process provides the required tolerance and surface quality.
- Test with the actual fluid: Use the real coolant, concentration, temperature, and exposure duration.
- Inspect after testing: Measure dimensions, appearance, weight, hardness, insulation, and mechanical performance.
- Validate the complete assembly: Test the coil, bobbin, encapsulant, valve, seals, and housing together.
- Control production quality: Define inspection criteria, batch traceability, and change-control procedures.
This system-level approach is more reliable than testing a plastic coupon in isolation.
Whether you need PEEK coil bobbins, PPS valve components, PEI electrical insulators, PPSU housings, or custom-machined engineering plastic parts, PRES can support the project from material selection through manufacturing.
Send PRES your:
- Part drawing or 3D model
- Required polymer or application conditions
- Coolant and temperature range
- Annual volume
- Tolerance and inspection requirements
Our team can help evaluate the most suitable material form and manufacturing route for your cooling-system application.
There is no universal best material. PEEK and PPS are strong candidates for demanding chemical, thermal, and dimensional requirements, while PPSU, PSU, and PEI may be suitable for specific structural, electrical, or toughness requirements.
Yes, PEEK can be considered for solenoid coil bobbins and related precision components when high temperature resistance, chemical resistance, wear resistance, and dimensional stability are required. The selected grade must be evaluated for the electrical and manufacturing requirements.
PPS is often considered for liquid-cooling valve components because of its low moisture absorption, chemical resistance, electrical insulation, and dimensional stability. Compatibility testing with the specific coolant remains essential.
Choose CNC machining for prototypes, complex low-volume parts, and rapid design changes. Choose injection molding for higher volumes, repeatability, and lower unit cost after tooling investment.
Test the candidate material in the actual coolant at realistic concentrations and temperatures. Include long-term exposure, thermal cycling, mechanical loading, and post-test dimensional and electrical inspections.
Yes. PRES supplies engineering plastic pellets, sheets, rods, and tubes and also provides CNC machining, injection molding, and custom processing for precision plastic components.
An effective RFQ should include the drawing, material preference, coolant type, operating temperature, pressure, tolerance, annual quantity, inspection requirements, and required certifications or documentation.
1. [RackSolutions, "Data Center Cooling: Trends and Insights for 2026"] — Market context and cooling-system growth.
2. [ResearchAndMarkets via Business Wire, "Data Center Liquid Cooling Market Outlook Report 2025"] — Liquid-cooling market drivers and direct-to-chip and immersion-cooling trends.
3. [UPSite, "Data Center Cooling Trends for 2025"] — Reported operator concerns, liquid-cooling adoption, integration complexity, and prefabricated cooling modules.
4. [IDTechEx, "Thermal Management for Data Centers 2026–2036"] — Forecast information and liquid-cooling component trends.
5. [Facilities Dive, "The 2025 Outlook for Data Center Cooling"] — AI workload intensity, hybrid cooling, and liquid-cooling requirements.
Reliable liquid cooling begins with system-level material selection. By combining application-specific testing with high-performance polymers and integrated CNC machining or injection molding, PRES helps data center and industrial customers reduce component risk and build more dependable thermal-management systems.
