PEEK 990GF30
PRES
PRES PEEK 990GF30 Sheet is a 30% glass fiber-reinforced polyetheretherketone (PEEK) composite Sheet.
The incorporation of glass fibers significantly enhances the material’s rigidity and creep resistance, enabling it to maintain minimal creep deformation and exceptional dimensional stability even under high static loads at elevated temperatures (>260°C).
Furthermore, this grade retains the inherent superior electrical properties of PEEK, exhibiting a volume resistivity as high as 1016 Ω·cm. Coupled with outstanding resistance to aggressive chemicals and low thermal conductivity, it addresses the diverse demands of high-end applications ranging from precision electrical insulation to high-temperature thermal management.
Heat deflection temp up to 310°C; continuous service at 260°C.
Short term service at 300°C
Melting point:343°C
Tensile strength 165 MPa; Flexural modulus 11 GPa. Ideal for metal replacement.
Low CTE (18 ppm/K) ensures precision in complex geometries.
Withstands aggressive chemicals, fuels, and hydraulic fluids.
Key Properties Utilized: High rigidity (11.3 GPa), Dimensional stability (CTE 18 ppm/K), Chemical resistance.
Wafer Handling Clips: Maintain tight tolerances at 260°C.
Test Socket Bodies: Replace metal with ESD-safe insulation.
Vacuum Pick-up Tools: High wear resistance without contaminating wafers.
Key Properties Utilized: High strength-to-weight ratio, Flame retardancy (UL94 V-0), Hydrolysis resistance.
Aircraft Interior Brackets: Metal replacement to reduce weight.
Radar System Components: Dimensional stability in extreme temps.
Fuel System Insulators: Resistant to aviation fuels and lubricants.
Key Properties Utilized: Continuous use at 260°C, Creep resistance, Oil & Grease resistance.
Transmission Thrust Washers: Withstand high loads and temperatures.
Fuel Cell Insulation Plates: Chemical inertness in acidic environments.
EV Battery Module Brackets: Flame retardant and lightweight structure.
Key Properties Utilized: Sterilizable (Autoclave), Radiolucency, Biocompatibility.
Surgical Instrument Handles: High rigidity and sterilizable.
Orthopedic Trial Implants: Dimensional accuracy for precise fitting.
Dental Device Components: Resistant to repeated chemical cleaning.
Key Properties Utilized: Low coefficient of friction, High wear resistance, Electrical insulation (10¹⁶ Ω·cm).
Compressor Valve Plates: Replace metal to reduce noise and wear.
Pump Wear Rings: Chemical resistance and dimensional stability.
High-Precision Gears: High modulus prevents tooth deflection.
Note: To allow for machining allowance, actual thickness is typically slightly greater than the nominal size listed below. Contact us for exact measured dimensions.
| Available Thickness (mm) | ||||||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 6 | 8 | 10 | 12 | 15 | 17 | 20 | 25 | 30 | 35 | 40 | 45 | 50 | 60 | 80 | 100 | 120 |
| 150 | 180 | 200 | 220 | 250 | 280 | 300 | Custom widths available upon request | |||||||||
| Property | Value | Unit | Test Standard |
|---|---|---|---|
| Density | 1.50 | g/cm³ | ISO 1183 |
| Tensile Strength | 175 | MPa | ISO 527 |
| Flexural Strength | 265 | MPa | ISO 178 |
| Flexural Modulus | 11.3 | GPa | ISO 178 |
| Coefficient of Thermal Expansion | 18 | ppm/K | ISO 11359 |
| Shore D Hardness | 88 | D | ISO 868 |
| Volume Resistivity | 1016 | Ω·cm | IEC 60093 |
| Flame Retardancy | V-0 | Class | UL 94 |
